profilermodule Module Reference

Data Types

type  measuredsectiontype
type  profilertype
 A public type for profiling performance in the application. The ProfilerType is used to measure and record the performance of various parts of the application. It provides mechanisms to start, stop, and. More...

Functions/Subroutines

subroutine pre_init (this)
subroutine initialize (this)
integer(i4b) function add_section (this, title, parent_id)
 Add a new timed section to the tree, passing the parent id will add it as a child.
subroutine start (this, title, section_id)
 Start section timing, add when not exist yet (i.e. when id < 1).
subroutine stop (this, section_id)
subroutine print (this, output_unit)
recursive subroutine print_section (this, section_id, level)
subroutine print_total (this, subtitle)
real(dp) function aggregate_walltime (this, title)
 Aggregate walltime over sections with a certain title.
integer(i4b) function aggregate_counts (this, title)
 Aggregate counts over sections with a certain title.
subroutine set_print_option (this, profile_option)
 Set the profile option from the user input.
subroutine destroy (this)
 Clean up the CPU timer object.
integer(i4b) function largest_title_length (this)
 Calculate the largest title length.
subroutine sort_by_walltime (this, idxs)
 Sort section indexes based on walltime.

Variables

integer(i4b), parameter max_sections_per_sln = 40
integer(i4b), parameter, public len_section_title = 128
type(profilertype), public g_prof
 the global timer object (to reduce trivial lines of code)

Function/Subroutine Documentation

◆ add_section()

integer(i4b) function profilermodule::add_section ( class(profilertype) this,
character(len=*) title,
integer(i4b) parent_id )
private

Definition at line 140 of file Profiler.f90.

141 use simmodule, only: ustop
142 class(ProfilerType) :: this
143 character(len=*) :: title
144 integer(I4B) :: parent_id
145 integer(I4B) :: section_id
146
147 ! increment to new section id
148 this%nr_sections = this%nr_sections + 1
149 section_id = this%nr_sections
150 if (section_id > size(this%all_sections)) then
151 write (*, *) "Internal error: Too many profiled sections, "&
152 &"disable profiling to circumvent."
153 call ustop()
154 end if
155
156 ! initialize new section
157 this%all_sections(section_id)%title = title
158 this%all_sections(section_id)%walltime = dzero
159 this%all_sections(section_id)%status = 0
160
161 ! if parent, otherwise root section
162 if (parent_id > 0) then
163 ! add child to parent
164 this%all_sections(section_id)%parent_id = parent_id
165 call this%all_sections(parent_id)%children%push_back(section_id)
166 else
167 ! this is the root, assume there's only one!
168 this%all_sections(section_id)%parent_id = 0
169 this%root_id = section_id
170 end if
171
This module contains simulation methods.
Definition Sim.f90:10
subroutine, public ustop(stopmess, ioutlocal)
Stop the simulation.
Definition Sim.f90:317
Here is the call graph for this function:

◆ aggregate_counts()

integer(i4b) function profilermodule::aggregate_counts ( class(profilertype) this,
character(len=*) title )
private

Definition at line 366 of file Profiler.f90.

367 class(ProfilerType) :: this
368 character(len=*) :: title
369 integer(I4B) :: counts
370 ! local
371 integer(I4B) :: i
372
373 counts = 0
374 do i = 1, this%nr_sections
375 if (index(this%all_sections(i)%title, trim(title)) > 0) then
376 counts = counts + this%all_sections(i)%count
377 end if
378 end do
379

◆ aggregate_walltime()

real(dp) function profilermodule::aggregate_walltime ( class(profilertype) this,
character(len=*) title )
private

Definition at line 348 of file Profiler.f90.

349 class(ProfilerType) :: this
350 character(len=*) :: title
351 real(DP) :: walltime
352 ! local
353 integer(I4B) :: i
354
355 walltime = dzero
356 do i = 1, this%nr_sections
357 if (index(this%all_sections(i)%title, trim(title)) > 0) then
358 walltime = walltime + this%all_sections(i)%walltime
359 end if
360 end do
361
Here is the caller graph for this function:

◆ destroy()

subroutine profilermodule::destroy ( class(profilertype) this)
private

Definition at line 403 of file Profiler.f90.

404 class(ProfilerType) :: this
405 ! local
406 integer(I4B) :: i
407
408 call this%callstack%destroy()
409
410 do i = 1, size(this%all_sections)
411 call this%all_sections(i)%children%destroy()
412 end do
413 deallocate (this%all_sections)
414 nullify (this%all_sections)
415

◆ initialize()

subroutine profilermodule::initialize ( class(profilertype) this)
private

Definition at line 84 of file Profiler.f90.

85 class(ProfilerType) :: this
86 ! local
87 character(len=LENMEMPATH) :: input_mempath
88 type(CharacterStringType), dimension(:), contiguous, &
89 pointer :: slntype
90 character(len=:), pointer :: prprof
91 integer(I4B) :: i
92 integer(I4B) :: max_sections
93 integer(I4B) :: nr_solutions
94
95 this%tmr_run = -1
96 this%tmr_init = -1
97 this%tmr_update = -1
98 this%tmr_finalize = -1
99 this%tmr_prep_tstp = -1
100 this%tmr_do_tstp = -1
101 this%tmr_final_tstp = -1
102 this%tmr_output = -1
103 this%tmr_nc_export = -1
104
105 call this%callstack%init()
106
107 ! get nr of solutions from input context
108 input_mempath = create_mem_path('SIM', 'NAM', idm_context)
109 call mem_setptr(slntype, 'SLNTYPE', input_mempath)
110 nr_solutions = size(slntype)
111 call mem_setptr(prprof, 'PRPROF', input_mempath)
112 call this%set_print_option(prprof)
113
114 max_sections = max_sections_per_sln * nr_solutions
115 allocate (this%all_sections(max_sections))
116 do i = 1, max_sections
117 this%all_sections(i)%title = "undefined"
118 this%all_sections(i)%status = 0
119 this%all_sections(i)%walltime = dzero
120 this%all_sections(i)%count = 0
121 this%all_sections(i)%parent_id = 0
122 call this%all_sections(i)%children%init()
123 end do
124
125 this%nr_sections = 0
126 this%root_id = 0
127 this%top_three = [0, 0, 0]
128
129 ! start root section here with previously recorded start time
130 if (this%pr_option > 0) then
131 call this%start("Run", this%tmr_run)
132 this%all_sections(this%tmr_run)%walltime = -this%sim_start_time
133 end if
134
Here is the call graph for this function:

◆ largest_title_length()

integer(i4b) function profilermodule::largest_title_length ( class(profilertype) this)
private

Definition at line 420 of file Profiler.f90.

421 class(ProfilerType) :: this
422 integer(I4B) :: max_length
423 integer(I4B) :: i
424
425 max_length = 0
426 do i = 1, this%nr_sections
427 max_length = max(max_length, len_trim(this%all_sections(i)%title))
428 end do
429

◆ pre_init()

subroutine profilermodule::pre_init ( class(profilertype) this)
private

Definition at line 75 of file Profiler.f90.

76 class(ProfilerType) :: this
77
78 call cpu_time(this%sim_start_time)
79

◆ print()

subroutine profilermodule::print ( class(profilertype) this,
integer(i4b), intent(in) output_unit )
private

Definition at line 227 of file Profiler.f90.

228 class(ProfilerType) :: this
229 integer(I4B), intent(in) :: output_unit
230 ! local
231 integer(I4B) :: level, i, top_idx
232 integer(I4B), dimension(:), allocatable :: sorted_idxs
233
234 if (this%pr_option == 0) return
235
236 this%iout = output_unit
237
238 ! get top three leaf sections based on walltime
239 top_idx = 1
240 sorted_idxs = (/(i, i=1, this%nr_sections)/)
241 call this%sort_by_walltime(sorted_idxs)
242 do i = 1, this%nr_sections
243 if (this%all_sections(sorted_idxs(i))%children%size == 0) then ! leaf node
244 if (top_idx > 3) exit
245 this%top_three(top_idx) = sorted_idxs(i)
246 top_idx = top_idx + 1
247 end if
248 end do
249
250 this%max_title_len = this%largest_title_length()
251
252 if (this%pr_option > 1) then
253 ! print timing call stack
254 level = 0
255 write (this%iout, '(/1x,a/)') &
256 repeat('-', 18)//" Profiler: Call Stack "//repeat('-', 18)
257 call this%print_section(this%root_id, level)
258 end if
259
260 ! print walltime per category from substring (if exist)
261 ! note: the sections containing the substring should not be nested,
262 ! otherwise the walltime will be counted multiple times
263 write (this%iout, '(1x,a/)') &
264 repeat('-', 20)//" Profiler: Totals "//repeat('-', 20)
265 call this%print_total("Formulate")
266 call this%print_total("Linear solve")
267 call this%print_total("Calculate flows")
268 call this%print_total("Calculate budgets")
269 call this%print_total("Write output")
270 call this%print_total("Parallel Solution")
271 call this%print_total("MPI_WaitAll")
272 write (this%iout, '(/1x,a/)') &
273 repeat('-', 22)//" End Profiler "//repeat('-', 22)
274
Here is the caller graph for this function:

◆ print_section()

recursive subroutine profilermodule::print_section ( class(profilertype) this,
integer(i4b) section_id,
integer(i4b) level )
private

Definition at line 277 of file Profiler.f90.

278 use arrayhandlersmodule, only: ifind
279 class(ProfilerType) :: this
280 integer(I4B) :: section_id
281 integer(I4B) :: level
282 ! local
283 integer(I4B) :: i, new_level, nr_padding, idx_top
284 real(DP) :: percent
285 type(MeasuredSectionType), pointer :: section
286 character(len=:), allocatable :: title_padded
287 character(len=LINELENGTH) :: top_marker
288
289 section => this%all_sections(section_id)
290
291 ! calculate percentage
292 percent = 1.0_dp
293 if (section%parent_id /= 0) then
294 percent = section%walltime / this%all_sections(this%root_id)%walltime
295 end if
296 percent = percent * 100.0_dp
297
298 ! determine if section should be marked as top three
299 top_marker = ""
300 idx_top = ifind(this%top_three, section_id)
301 if (idx_top > 0) then
302 nr_padding = max(0, 32 - level * 4)
303 write (top_marker, '(a,i0)') repeat(" ", nr_padding)//"<== #", idx_top
304 end if
305
306 ! print section timing
307 nr_padding = this%max_title_len - len_trim(section%title) + 2
308 title_padded = trim(section%title)//":"//repeat(' ', nr_padding)
309 write (this%iout, '(3a,f6.2,2a,f14.6,2a,i0,a,a)') " ", &
310 repeat('....', level), "[", percent, "%] ", title_padded, &
311 section%walltime, "s", " (", section%count, "x)", trim(top_marker)
312
313 ! print children
314 new_level = level + 1
315 do i = 1, section%children%size
316 call this%print_section(section%children%at(i), new_level)
317 end do
318
319 if (level == 0) write (this%iout, *)
320

◆ print_total()

subroutine profilermodule::print_total ( class(profilertype) this,
character(len=*) subtitle )
private

Definition at line 323 of file Profiler.f90.

324 class(ProfilerType) :: this
325 character(len=*) :: subtitle
326 ! local
327 integer(I4B) :: count
328 real(DP) :: walltime, percent
329 integer(I4B) :: nr_padding
330 character(len=:), allocatable :: title_padded
331
332 ! get maximum length of title
333 nr_padding = this%max_title_len - len_trim(subtitle)
334 title_padded = trim(subtitle)//repeat(' ', nr_padding)
335
336 count = this%aggregate_counts(subtitle)
337 if (count > 0) then
338 walltime = aggregate_walltime(this, subtitle)
339 percent = (walltime / this%all_sections(this%root_id)%walltime) * 100.0_dp
340 write (this%iout, '(2a,f6.2,3a,f14.6,2a,i0,a)') " ", "[", percent, &
341 "%] ", title_padded, ": ", walltime, "s", " (", count, "x)"
342 end if
343
Here is the call graph for this function:

◆ set_print_option()

subroutine profilermodule::set_print_option ( class(profilertype) this,
character(len=*), intent(in) profile_option )
private

Definition at line 384 of file Profiler.f90.

385 class(ProfilerType) :: this
386 character(len=*), intent(in) :: profile_option
387
388 select case (trim(profile_option))
389 case ("NONE")
390 this%pr_option = 0
391 case ("SUMMARY")
392 this%pr_option = 1
393 case ("DETAIL")
394 this%pr_option = 2
395 case default
396 this%pr_option = 0
397 end select
398

◆ sort_by_walltime()

subroutine profilermodule::sort_by_walltime ( class(profilertype) this,
integer(i4b), dimension(:), allocatable idxs )
private
Parameters
idxsarray with unsorted section idxs

Definition at line 434 of file Profiler.f90.

435 class(ProfilerType) :: this
436 integer(I4B), dimension(:), allocatable :: idxs !< array with unsorted section idxs
437 integer(I4B) :: i, j, temp
438
439 ! Simple bubble sort for demonstration purposes
440 do i = 1, size(idxs) - 1
441 do j = 1, size(idxs) - i
442 if (this%all_sections(idxs(j))%walltime < &
443 this%all_sections(idxs(j + 1))%walltime) then
444 temp = idxs(j)
445 idxs(j) = idxs(j + 1)
446 idxs(j + 1) = temp
447 end if
448 end do
449 end do
450

◆ start()

subroutine profilermodule::start ( class(profilertype) this,
character(len=*) title,
integer(i4b) section_id )
private

Definition at line 176 of file Profiler.f90.

177 class(ProfilerType) :: this
178 character(len=*) :: title
179 integer(I4B) :: section_id
180 ! local
181 integer(I4B) :: parent_id
182 real(DP) :: start_time
183 type(MeasuredSectionType), pointer :: section
184
185 if (this%pr_option == 0) return
186
187 call cpu_time(start_time)
188
189 if (section_id == -1) then
190 ! add section if not exist
191 parent_id = 0 ! root
192 if (this%callstack%size() > 0) then
193 parent_id = this%callstack%top()
194 end if
195 section_id = this%add_section(title, parent_id)
196 end if
197 call this%callstack%push(section_id)
198
199 section => this%all_sections(section_id)
200 section%count = section%count + 1
201 section%status = 1
202 section%walltime = section%walltime - start_time
203

◆ stop()

subroutine profilermodule::stop ( class(profilertype) this,
integer(i4b) section_id )
private

Definition at line 206 of file Profiler.f90.

207 class(ProfilerType) :: this
208 integer(I4B) :: section_id
209 ! local
210 real(DP) :: end_time
211 type(MeasuredSectionType), pointer :: section
212
213 if (this%pr_option == 0) return
214
215 call cpu_time(end_time)
216
217 ! nett result (c.f. start(...)) is adding (dt = end_time - start_time)
218 section => this%all_sections(section_id)
219 section%status = 0
220 section%walltime = section%walltime + end_time
221
222 ! pop from call stack
223 call this%callstack%pop()
224

Variable Documentation

◆ g_prof

type(profilertype), public profilermodule::g_prof

Definition at line 70 of file Profiler.f90.

70 type(ProfilerType), public :: g_prof !< the global timer object (to reduce trivial lines of code)

◆ len_section_title

integer(i4b), parameter, public profilermodule::len_section_title = 128

Definition at line 15 of file Profiler.f90.

◆ max_sections_per_sln

integer(i4b), parameter profilermodule::max_sections_per_sln = 40
private

Definition at line 14 of file Profiler.f90.
