MODFLOW 6 version 6.9.0.dev0
USGS Modular Hydrologic Model
|
Exchange PRP package. A variant of the normal PRP package that doesn't read from input files but instead receives particle transfers from coupled models while preserving the pattern where PRP packages own particles. Call it "Particle Registry Package"? More...


Public Member Functions | |
| procedure | prp_allocate_scalars (this) |
| Allocate scalars for exchange PRP. | |
| procedure | prp_allocate_arrays (this, nodelist, auxvar) |
| Allocate arrays for exchange PRP. | |
| procedure | source_dimensions (this) |
| Dimensions method override for exchange PRP. Just set all dimensions to zero and allocate arrays. | |
| procedure | source_options (this) |
| No-op options method override for exchange PRP. Just creates an empty release schedule. | |
| procedure | bnd_ar (this) |
| No-op AR method override for exchange PRP. | |
| procedure | bnd_rp (this) |
| No-op RP method override for exchange PRP. | |
| procedure | bnd_ad (this) |
| No-op AD method override for exchange PRP. | |
| procedure | bnd_cq_simrate (this, hnew, flowja, imover) |
| No-op flow calculation for exchange PRP. | |
| procedure | bnd_bd (this, model_budget) |
| No-op budget method for exchange PRP. Likewise about the STORAGE term accounting. | |
| procedure | bnd_ot_model_flows (this, icbcfl, ibudfl, icbcun, imap) |
| No-op flow output method for exchange PRP. No contribution to budget, no need to write output. | |
| procedure | prp_allocate_arrays (this, nodelist, auxvar) |
| Allocate arrays. | |
| procedure | prp_allocate_scalars (this) |
| Allocate scalars. | |
| procedure | bnd_ar (this) |
| Allocate and read period data. | |
| procedure | bnd_ar (this) |
| Allocate and read method for boundary package. | |
| procedure | bnd_ad (this) |
| Advance a time step and release particles if scheduled. | |
| procedure | bnd_ad (this) |
| Advance the package one time step. | |
| procedure | bnd_ad (this) |
| Advance the boundary package. | |
| procedure | bnd_rp (this) |
| Read and prepare period data for particle input. | |
| procedure | bnd_rp (this) |
| procedure | bnd_rp (this) |
| Allocate and read method for package. | |
| procedure | bnd_cq_simrate (this, hnew, flowja, imover) |
| Calculate flow between package and model. | |
| procedure | bnd_cq_simrate (this, hnew, flowja, imover) |
| Calculate simrate. | |
| procedure | bnd_da (this) |
| Deallocate memory. | |
| procedure | bnd_da (this) |
| Deallocate package memory. | |
| procedure | bnd_da (this) |
| Deallocate package memory. | |
| procedure | prp_commit (this) |
| Commit staged particle state to the "final" store. | |
| procedure | define_listlabel (this) |
| procedure | define_listlabel (this) |
| Define the list label for the package. | |
| procedure | prp_set_pointers (this, ibound, izone) |
| Set pointers to model variables. | |
| procedure | source_options (this) |
| Set options specific to PrtPrpType. | |
| procedure | source_options (this) |
| Source package options from input context. | |
| procedure | source_dimensions (this) |
| Set dimensions specific to PrtPrpType. | |
| procedure | source_dimensions (this) |
| Source package dimensions from input context. | |
| procedure | prp_log_options (this, found, trackfile, trackcsvfile) |
| Log options specific to PrtPrpType. | |
| procedure | prp_packagedata (this) |
| Load package data (release points). | |
| procedure | prp_releasetimes (this) |
| Load explicitly specified release times. | |
| procedure | prp_load_releasetimefrequency (this) |
| Load regularly spaced release times if configured. | |
| procedure | prp_load_default_release (this) |
| Release once at t=0 if the input configures no releases. | |
| procedure | prp_check_releases (this) |
| Warn if the input configures releases but none will happen. | |
| procedure | release (this, ip, trelease) |
| Release a particle at the specified time. | |
| procedure | log_release (this) |
| Log the release scheduled for this time step. | |
| procedure | validate_release_point (this, ic, x, y, z) |
| Verify that the release point is in the cell. | |
| procedure | initialize_particle (this, particle, ip, trelease) |
| procedure, public | bnd_obs_supported (this) |
| Indicates whether observations are supported. | |
| procedure, public | bnd_obs_supported (this) |
| Determine if observations are supported. | |
| procedure, public | bnd_df_obs (this) |
| Store supported observations. | |
| procedure, public | bnd_df_obs (this) |
| Define the observation types available in the package. | |
| procedure | bnd_df (this, neq, dis) |
| Define boundary package options and dimensions. | |
| procedure, public | bnd_df (this, neq, dis) |
| Define boundary package options and dimensions. | |
| procedure | bnd_rp_log (this) |
| Write the input list to the listing file if requested. | |
| procedure, public | bnd_rp_log (this) |
| Log period input for a boundary package. | |
| procedure | validate_ifno (this, ifno_val, nfeatures, nboundchk, feature_label, blockname) |
| Validate a list-input row's IFNO and update the per-feature coverage counter. | |
| procedure | report_ifno_coverage (this, nboundchk, nfeatures, feature_label, blockname, check_missing) |
| Report missing or duplicate list-input rows for each feature. | |
| procedure | allocate_scalars (this) |
| Allocate package scalars. | |
| procedure | allocate_scalars (this) |
| Allocate package scalars. | |
| procedure | allocate_scalars (this) |
| Allocate package scalars. | |
| procedure | allocate_arrays (this, nodelist, auxvar) |
| Allocate package arrays. | |
| procedure | allocate_arrays (this, nodelist, auxvar) |
| Allocate package arrays. | |
| procedure | allocate_featureauxvar (this) |
| Point the per-feature auxiliary variable array at the input context's permanent, feature-indexed AUX array. For packages with PACKAGEDATA AUX variables only. A live alias, permuted from row order to IFNO order, skipping out-of-range IFNO. | |
| procedure | log_options (this, found, sfacauxname) |
| Log package options. | |
| procedure | cellid_to_nlist (this) |
| Update package nodelist. | |
| procedure | nodeu_to_nlist (this) |
| Update package nodelist. | |
| procedure | layarr_to_nlist (this) |
| Update the nodelist based on layer number variable input. | |
| procedure | default_nodelist (this) |
| Assign default nodelist when READASARRAYS is specified. | |
| procedure | check_cellid (this, ii, cellid, mshape, ndim) |
| Check for valid cellid. | |
| procedure | write_lstfile (this) |
| Log package stress period input. | |
| procedure | bound_value (this, col, row) |
| Return a bound value. | |
| procedure | bnd_ac (this, moffset, sparse) |
| Add boundary package connection to matrix. | |
| procedure | bnd_mc (this, moffset, matrix_sln) |
| Map boundary package connection to matrix. | |
| procedure | bnd_ck (this) |
| Check boundary package period data. | |
| procedure | bnd_reset (this) |
| Reset bnd package before formulating. | |
| procedure | bnd_cf (this) |
| Formulate the package hcof and rhs terms. | |
| procedure | bnd_fc (this, rhs, ia, idxglo, matrix_sln) |
| Copy hcof and rhs terms into solution. | |
| procedure | bnd_fn (this, rhs, ia, idxglo, matrix_sln) |
| Add Newton-Raphson terms for package into solution. | |
| procedure | bnd_nur (this, neqpak, x, xtemp, dx, inewtonur, dxmax, locmax) |
| Apply Newton-Raphson under-relaxation for package. | |
| procedure | bnd_cc (this, innertot, kiter, iend, icnvgmod, cpak, ipak, dpak) |
| Convergence check for package. | |
| procedure | bnd_cq (this, x, flowja, iadv) |
| Calculate advanced package flows. | |
| procedure | bnd_bd (this, model_budget) |
| Add package flows to model budget. | |
| procedure | bnd_ot_model_flows (this, icbcfl, ibudfl, icbcun, imap) |
| Output package flow terms. | |
| procedure | bnd_ot_package_flows (this, icbcfl, ibudfl) |
| Output advanced package flow terms. | |
| procedure | bnd_ot_dv (this, idvsave, idvprint) |
| Output advanced package dependent-variable terms. | |
| procedure | bnd_ot_bdsummary (this, kstp, kper, iout, ibudfl) |
| Output advanced package budget summary. | |
| procedure | bnd_dt (this) |
| Submit an ATS time step request (no-op by default). | |
| procedure | bnd_fp (this) |
| Final processing at end of simulation (no-op by default). | |
| procedure | pack_initialize (this) |
| Allocate and initialize select package members. | |
| procedure | read_options (this) |
| Read additional options for package. | |
| procedure | read_dimensions (this) |
| Read dimensions for package. | |
| procedure | read_initial_attr (this) |
| Read initial parameters for package. | |
| procedure | bnd_options (this, option, found) |
| Read additional options for package. | |
| procedure | bnd_cq_simtomvr (this, flowja) |
| Calculate flow to the mover. | |
| procedure | set_pointers (this, neq, ibound, xnew, xold, flowja) |
| Set pointers to model variables. | |
| procedure | copy_boundname (this) |
| Copy boundnames into boundnames_cst. | |
| procedure, public | bnd_bd_obs (this) |
| Save observations for the package. | |
| procedure, public | bnd_ot_obs (this) |
| Output observations for the package. | |
| procedure, public | bnd_rp_obs (this) |
| Read and prepare observations for a package. | |
| procedure, public | bnd_rp_ts (this) |
| Assign time series links for the package. | |
| procedure, public | bnd_activate_viscosity (this) |
| Activate viscosity terms. | |
| procedure | set_names (this, ibcnum, name_model, pakname, ftype, input_mempath) |
| Set package names. | |
| procedure | da (this) |
| Deallocate package scalars. | |
| procedure | read_check_ionper (this) |
| Check ionper. | |
| procedure | get_block_data (this, tags, lfound, varinames) |
| Read griddata block for a package. | |
Public Attributes | |
| logical(lgp), pointer | extend => null() |
| extend tracking beyond simulation's end | |
| logical(lgp), pointer | frctrn => null() |
| force ternary solution for quad grids | |
| logical(lgp), pointer | drape => null() |
| whether to drape particle to topmost active cell | |
| logical(lgp), pointer | localz => null() |
| compute z coordinates local to the release cell | |
| integer(i4b), pointer | istopweaksink => null() |
| weak sink option: 0 = no stop, 1 = stop | |
| integer(i4b), pointer | istopzone => null() |
| optional stop zone number: 0 = no stop zone | |
| integer(i4b), pointer | idrymeth => null() |
| dry tracking method: 0 = drop, 1 = stop, 2 = stay | |
| integer(i4b), pointer | itrkout => null() |
| binary track file | |
| integer(i4b), pointer | itrkhdr => null() |
| track header file | |
| integer(i4b), pointer | itrkcsv => null() |
| CSV track file. | |
| integer(i4b), pointer | irlstls => null() |
| release time file | |
| integer(i4b), pointer | iexmeth => null() |
| method for iterative solution of particle exit location and time in generalized Pollock's method | |
| integer(i4b), pointer | ichkmeth => null() |
| method for checking particle release coordinates are in the specified cells, 0 = none, 1 = eager | |
| integer(i4b), pointer | icycwin => null() |
| cycle detection window size | |
| real(dp), pointer | extol => null() |
| tolerance for iterative solution of particle exit location and time in generalized Pollock's method | |
| real(dp), pointer | rttol => null() |
| tolerance for coincident particle release times | |
| real(dp), pointer | rtfreq => null() |
| frequency for regularly spaced release times | |
| real(dp), pointer | offset => null() |
| release time offset | |
| real(dp), pointer | stoptime => null() |
| stop time for all release points | |
| real(dp), pointer | stoptraveltime => null() |
| stop travel time for all points | |
| type(prtfmitype), pointer | fmi => null() |
| flow model interface | |
| type(particlestoretype), pointer | particles => null() |
| committed particle state (end of last successful time step) | |
| type(particlestoretype), pointer | particles_staging => null() |
| staging particle state for the current solve attempt | |
| type(particlereleasescheduletype), pointer | schedule => null() |
| particle release schedule | |
| integer(i4b), pointer | nreleasepoints => null() |
| number of release points | |
| integer(i4b), pointer | nreleasetimes => null() |
| number of user-specified particle release times | |
| integer(i4b), pointer | nparticles => null() |
| number of particles released | |
| integer(i4b), dimension(:), pointer, contiguous | rptnode => null() |
| release point reduced nns | |
| integer(i4b), dimension(:), pointer, contiguous | rptzone => null() |
| release point zone numbers | |
| real(dp), dimension(:), pointer, contiguous | rptx => null() |
| release point x coordinates | |
| real(dp), dimension(:), pointer, contiguous | rpty => null() |
| release point y coordinates | |
| real(dp), dimension(:), pointer, contiguous | rptz => null() |
| release point z coordinates | |
| real(dp), dimension(:), pointer, contiguous | rptm => null() |
| total mass released from point | |
| character(len=lenboundname), dimension(:), pointer, contiguous | rptname => null() |
| release point names | |
| character(len=linelength), dimension(:), allocatable | period_block_lines |
| last period block configuration for fill-forward | |
| integer(i4b) | applied_kper |
| period for which configuration was last applied | |
| integer(i4b), pointer | iper |
| logical(lgp), pointer | readarraygrid |
| logical(lgp), pointer | readasarrays |
| logical(lgp), pointer | ts_active |
| .true. if TS6 files are configured in OPTIONS | |
| integer(i4b), dimension(:, :), pointer, contiguous | cellid => null() |
| input user cellid list | |
| integer(i4b), dimension(:), pointer, contiguous | nodeulist => null() |
| input user nodelist | |
| integer(i4b), dimension(:), pointer, contiguous | pkg_ifno => null() |
| advanced feature index | |
| real(dp), dimension(:, :), pointer, contiguous | featureauxvar => null() |
| advanced per-feature AUX array | |
| character(len=lenlistlabel), pointer | listlabel => null() |
| title of table written for RP | |
| character(len=lenpackagename) | text = '' |
| text string for package flow term | |
| character(len=lenauxname), dimension(:), pointer, contiguous | auxname => null() |
| vector of auxname | |
| type(characterstringtype), dimension(:), pointer, contiguous | auxname_cst => null() |
| copy of vector auxname that can be stored in memory manager | |
| character(len=lenboundname), dimension(:), pointer, contiguous | boundname => null() |
| vector of boundnames | |
| type(characterstringtype), dimension(:), pointer, contiguous | boundname_cst => null() |
| copy of vector boundname that can be stored in memory manager | |
| integer(i4b), pointer | isadvpak => null() |
| flag indicating package is advanced (1) or not (0) | |
| integer(i4b), pointer | ibcnum => null() |
| consecutive package number for this boundary condition | |
| integer(i4b), pointer | maxbound => null() |
| max number of boundaries | |
| integer(i4b), pointer | nbound => null() |
| number of boundaries for current stress period | |
| integer(i4b), pointer | ncolbnd => null() |
| number of columns of the bound array | |
| integer(i4b), pointer | iscloc => null() |
| bound column to scale with SFAC | |
| integer(i4b), pointer | naux => null() |
| number of auxiliary variables | |
| integer(i4b), pointer | inamedbound => null() |
| flag to read boundnames | |
| integer(i4b), pointer | iauxmultcol => null() |
| column to use as multiplier for column iscloc | |
| integer(i4b), pointer | npakeq => null() |
| number of equations in this package (normally 0 unless package adds rows to matrix) | |
| integer(i4b), pointer | ioffset => null() |
| offset of this package in the model | |
| integer(i4b), dimension(:), pointer, contiguous | nodelist => null() |
| vector of reduced node numbers | |
| integer(i4b), dimension(:), pointer, contiguous | noupdateauxvar => null() |
| override auxvars from being updated | |
| real(dp), dimension(:, :), pointer, contiguous | bound => null() |
| array of package specific boundary numbers | |
| real(dp), dimension(:), pointer, contiguous | hcof => null() |
| diagonal contribution | |
| real(dp), dimension(:), pointer, contiguous | rhs => null() |
| right-hand side contribution | |
| real(dp), dimension(:, :), pointer, contiguous | auxvar => null() |
| auxiliary variable array | |
| real(dp), dimension(:), pointer, contiguous | simvals => null() |
| simulated values | |
| real(dp), dimension(:), pointer, contiguous | simtomvr => null() |
| simulated to mover values | |
| integer(i4b), pointer | imover => null() |
| flag indicating if the mover is active in the package | |
| type(packagemovertype), pointer | pakmvrobj => null() |
| mover object for package | |
| integer(i4b), pointer | ivsc => null() |
| flag indicating if viscosity is active in the model | |
| real(dp), dimension(:), pointer, contiguous | condinput => null() |
| stores user-specified conductance values | |
| real(dp), dimension(:), allocatable | viscratio |
| viscosity ratio applied to each boundary conductance | |
| type(timeseriesmanagertype), pointer | tsmanager => null() |
| time series manager | |
| type(timearrayseriesmanagertype), pointer | tasmanager => null() |
| time array series manager | |
| integer(i4b) | indxconvertflux = 0 |
| indxconvertflux is column of bound to multiply by area to convert flux to rate | |
| logical(lgp) | allowtimearrayseries = .false. |
| integer(i4b), pointer | inobspkg => null() |
| unit number for obs package | |
| type(obstype), pointer | obs => null() |
| observation package | |
| integer(i4b), pointer | neq |
| number of equations for model | |
| integer(i4b), dimension(:), pointer, contiguous | ibound => null() |
| model ibound array | |
| real(dp), dimension(:), pointer, contiguous | xnew => null() |
| model dependent variable (head) for this time step | |
| real(dp), dimension(:), pointer, contiguous | xold => null() |
| model dependent variable for last time step | |
| real(dp), dimension(:), pointer, contiguous | flowja => null() |
| model intercell flows | |
| integer(i4b), dimension(:), pointer, contiguous | icelltype => null() |
| pointer to icelltype array in NPF | |
| character(len=lenmempath) | ictmempath = '' |
| memory path to the icelltype data (for GWF this is in NPF) | |
| type(tabletype), pointer | inputtab => null() |
| input table object | |
| type(tabletype), pointer | outputtab => null() |
| output table object for package flows writtent to the model listing file | |
| type(tabletype), pointer | errortab => null() |
| package error table | |
| character(len=lenmodelname) | name_model = '' |
| the name of the model that contains this package | |
| character(len=lenpackagename) | packname = '' |
| name of the package | |
| character(len=lenmempath) | memorypath = '' |
| the location in the memory manager where the variables are stored | |
| character(len=lenmempath) | memorypathmodel = '' |
| the location in the memory manager where the variables of the parent model are stored | |
| character(len=lenmempath) | input_mempath = '' |
| input context mempath | |
| character(len=linelength), pointer | input_fname => null() |
| input file name | |
| character(len=lenftype) | filtyp = '' |
| file type (CHD, DRN, RIV, etc.) | |
| character(len=lenftype), pointer | package_type => null() |
| package type (same as filtyp) stored in memory manager | |
| integer(i4b), pointer | id => null() |
| consecutive package number in model | |
| integer(i4b), pointer | inunit => null() |
| unit number for input file | |
| integer(i4b), pointer | iout => null() |
| unit number for writing package output | |
| integer(i4b), pointer | inewton => null() |
| newton flag | |
| integer(i4b), pointer | iasym => null() |
| package causes matrix asymmetry | |
| integer(i4b), pointer | iprpak => null() |
| integer flag to echo input | |
| integer(i4b), pointer | iprflow => null() |
| flag to print simulated flows | |
| integer(i4b), pointer | ipakcb => null() |
| output flows (-1, 0, 1) - save_flows | |
| integer(i4b), pointer | ionper => null() |
| stress period for next data | |
| integer(i4b), pointer | lastonper => null() |
| last value of ionper (for checking) | |
| type(blockparsertype) | parser |
| parser object for reading blocks of information | |
| class(disbasetype), pointer | dis => null() |
| model discretization object | |
Private Member Functions | |
| procedure, private | pak_setup_outputtab (this) |
| Setup output table for package. | |
Definition at line 109 of file prt-prp.f90.
|
inherited |
Allocate and initialize base boundary package arrays. This method only needs to be overridden if additional arrays are defined for a specific package.
| this | BndExtType object |
| nodelist | package nodelist |
| auxvar | package aux variable array |
Definition at line 54 of file BoundaryPackageExt.f90.
|
inherited |
Allocate and initialize base boundary package arrays. This method only needs to be overridden if additional arrays are defined for a specific package.
| this | BndType object |
| nodelist | package nodelist |
| auxvar | package aux variable array |
Definition at line 140 of file BoundaryPackage.f90.
|
inherited |
| this | BndExtType object |
Definition at line 55 of file BoundaryPackageExt.f90.
|
inherited |
Allocate and initialize base boundary package scalars. This method only needs to be overridden if additional scalars are defined for a specific package.
| this | BndExtType object |
Definition at line 53 of file BoundaryPackageExt.f90.
|
inherited |
Allocate and initialize base boundary package scalars. This method only needs to be overridden if additional scalars are defined for a specific package.
| this | BndType object |
Definition at line 139 of file BoundaryPackage.f90.
|
inherited |
Allocate and initialize base numerical package scalars.
| this | NumericalPackageType object |
Definition at line 54 of file NumericalPackage.f90.
|
inherited |
Add boundary package connection to the matrix for packages that add connections to the coefficient matrix. An example would be the GWF model MAW package. Base implementation that must be extended.
| [in,out] | this | BndType object |
| [in] | moffset | solution matrix model offset |
| [in,out] | sparse | sparse object |
Definition at line 117 of file BoundaryPackage.f90.
|
inherited |
Method to activate addition of viscosity terms when package type is DRN, GHB, or RIV (method not needed by other packages at this point)
| [in,out] | this | BndType object |
Definition at line 165 of file BoundaryPackage.f90.
|
inherited |
Does not call thisTsManagerad()/thisTasManagerad() – those managers are unused by this type (see bndext_df).
Definition at line 47 of file BoundaryPackageExt.f90.
|
inherited |
Advance data in the boundary package. The method sets advances time series, time array series, and observation data. A boundary package only needs to override this method if additional data needs to be advanced.
| this | BndType object |
Definition at line 121 of file BoundaryPackage.f90.
| procedure prtprpmodule::exgprtprptype::bnd_ad | ( | class(exgprtprptype) | this | ) |
Definition at line 117 of file prt-prp.f90.
|
inherited |
Definition at line 82 of file prt-prp.f90.
|
inherited |
Generic method to allocate and read static data for model boundary packages. A boundary package only needs to override this method if input data varies from the standard boundary package.
| [in,out] | this | BndType object |
Definition at line 119 of file BoundaryPackage.f90.
| procedure prtprpmodule::exgprtprptype::bnd_ar | ( | class(exgprtprptype), intent(inout) | this | ) |
Definition at line 115 of file prt-prp.f90.
|
inherited |
Definition at line 81 of file prt-prp.f90.
|
inherited |
Add the flow between package and the model (ratin and ratout) to the model budget. This method only needs to be overridden if a different calculation needs to be made.
| this | BndType object | |
| [in,out] | model_budget | model budget object |
Definition at line 130 of file BoundaryPackage.f90.
| procedure prtprpmodule::exgprtprptype::bnd_bd | ( | class(exgprtprptype) | this, |
| type(budgettype), intent(inout) | model_budget ) |
Definition at line 119 of file prt-prp.f90.
|
inherited |
Method to save simulated values for the boundary package. This method will need to be overridden for boundary packages with more observations than the calculate flow term (simvals) and to-mover.
| this | BndType object |
Definition at line 156 of file BoundaryPackage.f90.
|
inherited |
Perform additional convergence checks on the flow between the package and the model it is attached to. This additional convergence check is applied to packages that solve their own continuity equation as part of the formulate step at the beginning of a Picard iteration. A boundary package only needs to override this method if a specific boundary package solves its own continuity equation. Example packages that implement this additional convergence check is the CSUB, SFR, LAK, and UZF packages.
| [in,out] | this | BndType object |
| [in] | innertot | total number of inner iterations |
| [in] | kiter | Picard iteration number |
| [in] | iend | flag indicating if this is the last Picard iteration |
| [in] | icnvgmod | flag inficating if the model has met specific convergence criteria |
| [in,out] | cpak | string for user node |
| [in,out] | ipak | location of the maximum dependent variable change |
| [in,out] | dpak | maximum dependent variable change |
Definition at line 128 of file BoundaryPackage.f90.
|
inherited |
Formulate the hcof and rhs terms for the package that will be added to the coefficient matrix and right-hand side vector. Base implementation that must be extended by each model boundary package.
| this | BndType object |
Definition at line 124 of file BoundaryPackage.f90.
|
inherited |
Check the boundary package period data. Base implementation that must be extended by each model boundary package.
| [in,out] | this | BndType object |
Definition at line 122 of file BoundaryPackage.f90.
|
inherited |
Calculate the flow between connected advanced package control volumes. Only advanced boundary packages need to override this method.
| [in,out] | this | BndType object |
| [in] | x | current dependent-variable value |
| [in,out] | flowja | flow between two connected control volumes |
| [in] | iadv | flag that indicates if this is an advance package |
Definition at line 129 of file BoundaryPackage.f90.
|
inherited |
Calculate the flow between package and the model (for example, GHB and groundwater cell) and store in the simvals variable. This method only needs to be overridden if a different calculation needs to be made.
| this | BndType object | |
| [in] | hnew | current dependent-variable value |
| [in,out] | flowja | flow between package and model |
| [in] | imover | flag indicating if the mover package is active |
Definition at line 146 of file BoundaryPackage.f90.
| procedure prtprpmodule::exgprtprptype::bnd_cq_simrate | ( | class(exgprtprptype) | this, |
| real(dp), dimension(:), intent(in) | hnew, | ||
| real(dp), dimension(:), intent(inout) | flowja, | ||
| integer(i4b), intent(in) | imover ) |
Exchange PRP particles are transferred from other models and already active, so their mass is already accounted for in the STORAGE term.
Definition at line 118 of file prt-prp.f90.
|
inherited |
| [in,out] | flowja | flow between package and model |
| [in] | imover | flag indicating if the mover package is active |
Definition at line 84 of file prt-prp.f90.
|
inherited |
Calculate the flow between package and the model that is sent to the mover package and store in the simtomvr variable. This method only needs to be overridden if a different calculation needs to be made.
| this | BndType object | |
| [in,out] | flowja | flow between package and model |
Definition at line 147 of file BoundaryPackage.f90.
|
inherited |
| this | BndExtType object |
Definition at line 52 of file BoundaryPackageExt.f90.
|
inherited |
Deallocate base boundary package scalars and arrays. This method only needs to be overridden if additional variables are defined for a specific package.
| this | BndType object |
Definition at line 137 of file BoundaryPackage.f90.
|
inherited |
Definition at line 85 of file prt-prp.f90.
|
inherited |
Define base boundary package options and dimensions for a model boundary package.
| [in,out] | this | BndExtType object |
| [in,out] | neq | number of equations |
| dis | discretization object |
Definition at line 46 of file BoundaryPackageExt.f90.
|
inherited |
Define base boundary package options and dimensions for a model boundary package.
| [in,out] | this | BndType object |
| [in,out] | neq | number of equations |
| dis | discretization object |
Definition at line 116 of file BoundaryPackage.f90.
|
inherited |
Method to define the observation types available in a boundary package. This method should be overridden if observations are supported in a boundary package.
| this | BndType object |
Definition at line 155 of file BoundaryPackage.f90.
|
inherited |
Definition at line 102 of file prt-prp.f90.
|
inherited |
| this | BndType object |
Definition at line 135 of file BoundaryPackage.f90.
|
inherited |
Add the hcof and rhs terms for the boundary package to the coefficient matrix and right-hand side vector. A boundary package only needs to override this method if it is different for a specific boundary package.
| this | BndType object | |
| [in,out] | rhs | right-hand side vector for model |
| [in] | ia | solution CRS row pointers |
| [in] | idxglo | mapping vector for model (local) to solution (global) |
| matrix_sln | solution coefficient matrix |
Definition at line 125 of file BoundaryPackage.f90.
|
inherited |
Calculate and add the Newton-Raphson terms for the boundary package to the coefficient matrix and right-hand side vector. A boundary package only needs to override this method if a specific boundary package needs to add Newton-Raphson terms.
| this | BndType object | |
| [in,out] | rhs | right-hand side vector for model |
| [in] | ia | solution CRS row pointers |
| [in] | idxglo | mapping vector for model (local) to solution (global) |
| matrix_sln | solution coefficient matrix |
Definition at line 126 of file BoundaryPackage.f90.
|
inherited |
| this | BndType object |
Definition at line 136 of file BoundaryPackage.f90.
|
inherited |
Map boundary package connection to the matrix for packages that add connections to the coefficient matrix. An example would be the GWF model MAW package. Base implementation that must be extended.
| [in,out] | this | BndType object |
| [in] | moffset | solution matrix model offset |
| matrix_sln | global system matrix |
Definition at line 118 of file BoundaryPackage.f90.
|
inherited |
Apply Newton-Raphson under-relaxation for a boundary package. A boundary package only needs to override this method if a specific boundary package needs to apply Newton-Raphson under-relaxation. An example is the MAW package which adds rows to the system of equations and may need to have the dependent-variable constrained by the bottom of the model.
| [in,out] | this | BndType object |
| [in] | neqpak | number of equations in the package |
| [in,out] | x | dependent variable |
| [in] | xtemp | previous dependent variable |
| [in,out] | dx | change in dependent variable |
| [in,out] | inewtonur | flag indicating if newton-raphson under-relaxation should be applied |
| [in,out] | dxmax | maximum change in the dependent variable |
| [in,out] | locmax | location of the maximum change in the dependent variable |
Definition at line 127 of file BoundaryPackage.f90.
|
inherited |
Function to determine if observations are supported by the boundary package. By default, observations are not supported. This method should be overridden if observations are supported in a boundary package.
| this | BndType object |
Definition at line 154 of file BoundaryPackage.f90.
|
inherited |
Definition at line 101 of file prt-prp.f90.
|
inherited |
Read additional options for a boundary package. This method should be overridden options in addition to the base options are implemented in a boundary package.
| [in,out] | this | BndType object |
| [in,out] | option | option keyword string |
| [in,out] | found | boolean indicating if the option was found |
Definition at line 145 of file BoundaryPackage.f90.
|
inherited |
Output advanced boundary package budget summary. This method only needs to be overridden for advanced packages that save budget summaries to the model listing file.
| this | BndType object | |
| [in] | kstp | time step number |
| [in] | kper | period number |
| [in] | iout | flag and unit number for the model listing file |
| [in] | ibudfl | flag indicating budget should be written |
Definition at line 134 of file BoundaryPackage.f90.
|
inherited |
Output advanced boundary package dependent-variable terms. This method only needs to be overridden for advanced packages that save dependent variable terms for each control volume.
| this | BndType object | |
| [in] | idvsave | flag and unit number for dependent-variable output |
| [in] | idvprint | flag indicating if dependent-variable should be written to the model listing file |
Definition at line 133 of file BoundaryPackage.f90.
|
inherited |
Output flow terms between the boundary package and model to a binary file and/or print flows to the model listing file. This method should not need to be overridden.
| this | BndType object | |
| [in] | icbcfl | flag for cell-by-cell output |
| [in] | ibudfl | flag indication if cell-by-cell data should be saved |
| [in] | icbcun | unit number for cell-by-cell output |
| [in] | imap | mapping vector that converts the 1 to nbound values to lake number, maw number, etc. |
Definition at line 131 of file BoundaryPackage.f90.
| procedure prtprpmodule::exgprtprptype::bnd_ot_model_flows | ( | class(exgprtprptype) | this, |
| integer(i4b), intent(in) | icbcfl, | ||
| integer(i4b), intent(in) | ibudfl, | ||
| integer(i4b), intent(in) | icbcun, | ||
| integer(i4b), dimension(:), intent(in), optional | imap ) |
Definition at line 120 of file prt-prp.f90.
|
inherited |
Method to output simulated values for the boundary package. This method should not need to be overridden.
| this | BndType object |
Definition at line 157 of file BoundaryPackage.f90.
|
inherited |
Output advanced boundary package flow terms. This method only needs to be overridden for advanced packages that save flow terms than contribute to the continuity equation for each control volume.
| this | BndType object | |
| [in] | icbcfl | flag and unit number for cell-by-cell output |
| [in] | ibudfl | flag indication if cell-by-cell data should be saved |
Definition at line 132 of file BoundaryPackage.f90.
|
inherited |
| this | BndType object |
Definition at line 123 of file BoundaryPackage.f90.
|
inherited |
| [in,out] | this | BndExtType object |
Definition at line 48 of file BoundaryPackageExt.f90.
|
inherited |
Generic method to read and prepare period data for model boundary packages. A boundary package only needs to override this method if period data varies from the standard boundary package.
| [in,out] | this | BndType object |
Definition at line 120 of file BoundaryPackage.f90.
| procedure prtprpmodule::exgprtprptype::bnd_rp | ( | class(exgprtprptype), intent(inout) | this | ) |
Definition at line 116 of file prt-prp.f90.
|
inherited |
Definition at line 83 of file prt-prp.f90.
|
inherited |
Called from model control files after bnd_rp(), which ensures bound_value() dispatches to the correct derived type.
Definition at line 49 of file BoundaryPackageExt.f90.
|
inherited |
Write stress period input to the listing file if requested. This default implementation is a no-op; BndExtType overrides it.
Definition at line 159 of file BoundaryPackage.f90.
|
inherited |
Method to read and prepare observations for a boundary package This method should not need to be overridden for most boundary packages.
| [in,out] | this | BndType object |
Definition at line 158 of file BoundaryPackage.f90.
|
inherited |
Assign the time series links for the boundary package. This method will need to be overridden for boundary packages that support time series.
Definition at line 162 of file BoundaryPackage.f90.
|
inherited |
Return a bound value associated with an ncolbnd index and row. This function should be overridden in the derived package class.
| [in,out] | this | BndExtType object |
Definition at line 65 of file BoundaryPackageExt.f90.
|
inherited |
Convert period updated cellids to node numbers.
| this | BndExtType object |
Definition at line 59 of file BoundaryPackageExt.f90.
|
inherited |
| this | BndExtType object | |
| [in] | mshape | model shape |
| [in] | ndim | size of mshape |
Definition at line 63 of file BoundaryPackageExt.f90.
|
inherited |
boundnames_cst is an array of type(CharacterStringType), which can be stored in the MemoryManager.
| [in,out] | this | BndType object |
Definition at line 150 of file BoundaryPackage.f90.
|
inherited |
Deallocate and initialize base numerical package scalars.
| this | NumericalPackageType object |
Definition at line 55 of file NumericalPackage.f90.
|
inherited |
Equivalent to reading layer number array as CONSTANT 1
Definition at line 62 of file BoundaryPackageExt.f90.
|
inherited |
Method defined the list label for the boundary package. This method needs to be overridden by each boundary package.
| [in,out] | this | BndType object |
Definition at line 149 of file BoundaryPackage.f90.
|
inherited |
Definition at line 87 of file prt-prp.f90.
|
inherited |
Generic method to read data in the GRIDDATA block for a package.
| this | NumericalPackageType object | |
| [in] | tags | vector with variable tags |
| [in,out] | lfound | boolean vector indicating of a variable tag was found |
| [in] | varinames | optional vector of variable names |
Definition at line 57 of file NumericalPackage.f90.
|
inherited |
| [in,out] | this | this instance |
| [in,out] | particle | the particle |
| [in] | ip | particle index |
| [in] | trelease | release time |
Definition at line 100 of file prt-prp.f90.
|
inherited |
This is a module scoped routine to check for I<filtyp> input. If array input was provided, INI<filtyp> and I<filtyp> will be allocated in the input context. If the read state variable INI<filtyp> shows values were given in this period block, I<filtyp> input was read and is used here to update the nodelist.
| this | BndExtType object |
Definition at line 61 of file BoundaryPackageExt.f90.
|
inherited |
| [in,out] | this | BndExtType object |
Definition at line 57 of file BoundaryPackageExt.f90.
|
inherited |
| [in,out] | this | prp |
Definition at line 98 of file prt-prp.f90.
|
inherited |
Convert period user nodes to reduced nodes. Inactive cells are excluded by the input loader.
| this | BndExtType object |
Definition at line 60 of file BoundaryPackageExt.f90.
|
inherited |
Allocate and initialize select base boundary package members. This method needs to be overridden by a package if it is needed for a specific package.
| this | BndType object |
Definition at line 141 of file BoundaryPackage.f90.
|
privateinherited |
Setup output table for a boundary package that is used to output package to model flow terms to the model listing file.
| [in,out] | this | BndType object |
Definition at line 151 of file BoundaryPackage.f90.
| procedure prtprpmodule::exgprtprptype::prp_allocate_arrays | ( | class(exgprtprptype) | this, |
| integer(i4b), dimension(:), optional, pointer, contiguous | nodelist, | ||
| real(dp), dimension(:, :), optional, pointer, contiguous | auxvar ) |
BndExtType expects certain array variables to exist in the input context (CELLID, NODEULIST, BOUNDNAME, AUXVAR). This method manually creates zero-sized arrays before calling the parent's allocate_arrays.
Definition at line 112 of file prt-prp.f90.
|
inherited |
Definition at line 79 of file prt-prp.f90.
| procedure prtprpmodule::exgprtprptype::prp_allocate_scalars | ( | class(exgprtprptype) | this | ) |
The exchange PRP is a headless package (no input file) but BndExtType expects certain variables to exist in the input context (IPER, IONPER, HASPERIODBLOCKS) so we need to manually create them before calling the parent procedure.
Definition at line 111 of file prt-prp.f90.
|
inherited |
Definition at line 80 of file prt-prp.f90.
|
inherited |
Call after release times, the release time frequency and the default are loaded. Then an empty time selection means no time-based releases, and IONPER still holds the first period block's number, or nper + 1 if there is no block to load.
Definition at line 96 of file prt-prp.f90.
|
inherited |
Definition at line 86 of file prt-prp.f90.
|
inherited |
The default depends on the input only: no explicit release times, no release time frequency, and no period blocks. It doesn't depend on the schedule, which only holds the times that will be used, so explicit times that are all dropped don't trigger the default.
The exchange PRP doesn't get this default, on purpose: it carries particles between models and never calls prp_dimensions.
Definition at line 95 of file prt-prp.f90.
|
inherited |
Definition at line 94 of file prt-prp.f90.
|
inherited |
Definition at line 91 of file prt-prp.f90.
|
inherited |
Definition at line 92 of file prt-prp.f90.
|
inherited |
Definition at line 93 of file prt-prp.f90.
|
inherited |
Definition at line 88 of file prt-prp.f90.
|
inherited |
Generic method to read and check ionperiod, which is used to determine if new period data should be read from the input file. The check of ionperiod also makes sure periods are increasing in subsequent period data blocks.
| [in,out] | this | NumericalPackageType object |
Definition at line 56 of file NumericalPackage.f90.
|
inherited |
Read base dimensions for boundary packages. This method should not need to be overridden unless more than MAXBOUND is specified in the DIMENSIONS block.
| [in,out] | this | BndType object |
Definition at line 143 of file BoundaryPackage.f90.
|
inherited |
Read initial parameters for a boundary package. This method is not needed for most boundary packages. The SFR package is an example of a package that has overridden this method.
| [in,out] | this | BndType object |
Definition at line 144 of file BoundaryPackage.f90.
|
inherited |
Read base options for boundary packages.
| [in,out] | this | BndType object |
Definition at line 142 of file BoundaryPackage.f90.
|
inherited |
Releasing a particle entails validating the particle's coordinates and settings, transforming its coordinates if needed, initializing the particle's initial tracking time to the given release time, storing the particle in the particle store (from which the PRT model will later retrieve it, apply the tracking method, and check it in again), and accumulating the particle's mass (the total mass released from each release point is calculated for budget reporting).
| [in,out] | this | this instance |
| [in] | ip | particle index |
| [in] | trelease | release time |
Definition at line 97 of file prt-prp.f90.
|
inherited |
Set check_missing=.false. for an optional block where not every feature is expected to have a row (duplicates are still reported).
Definition at line 51 of file BoundaryPackageExt.f90.
|
inherited |
Method to assign the filtyp (ftype), the model name, and package name for a package. This method also creates the memoryPath and memoryPathModel that is used by the memory manager when variables are allocated.
| [in,out] | this | NumericalPackageType object |
| [in] | ibcnum | unique package number |
| [in] | name_model | name of the model |
| [in] | pakname | name of the package |
| [in] | ftype | package type |
Definition at line 53 of file NumericalPackage.f90.
|
inherited |
Set pointers to model variables so that a package has access to these variables. This base method should not need to be overridden.
| this | BndType object |
| neq | number of equations in the model |
| ibound | model idomain |
| xnew | current dependent variable |
| xold | previous dependent variable |
| flowja | connection flow terms |
Definition at line 148 of file BoundaryPackage.f90.
|
inherited |
| [in,out] | this | BndExtType object |
Definition at line 58 of file BoundaryPackageExt.f90.
| procedure prtprpmodule::exgprtprptype::source_dimensions | ( | class(exgprtprptype), intent(inout) | this | ) |
Definition at line 113 of file prt-prp.f90.
|
inherited |
Definition at line 90 of file prt-prp.f90.
|
inherited |
| [in,out] | this | BndExtType object |
Definition at line 56 of file BoundaryPackageExt.f90.
| procedure prtprpmodule::exgprtprptype::source_options | ( | class(exgprtprptype), intent(inout) | this | ) |
Definition at line 114 of file prt-prp.f90.
|
inherited |
Definition at line 89 of file prt-prp.f90.
|
inherited |
Returns the validated feature index, or 0 if out of range (an error is logged; the caller should skip further processing for the row).
Definition at line 50 of file BoundaryPackageExt.f90.
|
inherited |
Terminate with an error if the release point lies outside the given cell, or if the point is above or below the grid top or bottom, respectively.
| [in,out] | this | this instance |
| [in] | ic | cell index |
| [in] | z | release point |
Definition at line 99 of file prt-prp.f90.
|
inherited |
Log period based input. This routine requires a package specific bound_value() routine to report accurate bound values.
| this | BndExtType object |
Definition at line 64 of file BoundaryPackageExt.f90.
|
inherited |
Definition at line 95 of file BoundaryPackage.f90.
|
inherited |
Definition at line 77 of file prt-prp.f90.
|
inherited |
Definition at line 51 of file BoundaryPackage.f90.
|
inherited |
Definition at line 53 of file BoundaryPackage.f90.
|
inherited |
Definition at line 78 of file BoundaryPackage.f90.
|
inherited |
Definition at line 75 of file BoundaryPackage.f90.
|
inherited |
Definition at line 55 of file BoundaryPackage.f90.
|
inherited |
Definition at line 57 of file BoundaryPackage.f90.
|
inherited |
Definition at line 40 of file BoundaryPackageExt.f90.
|
inherited |
Definition at line 88 of file BoundaryPackage.f90.
|
inherited |
Definition at line 50 of file NumericalPackage.f90.
|
inherited |
Definition at line 43 of file prt-prp.f90.
|
inherited |
Definition at line 113 of file BoundaryPackage.f90.
|
inherited |
Definition at line 41 of file prt-prp.f90.
|
inherited |
Definition at line 55 of file prt-prp.f90.
|
inherited |
Definition at line 44 of file BoundaryPackageExt.f90.
|
inherited |
Definition at line 33 of file NumericalPackage.f90.
|
inherited |
Definition at line 106 of file BoundaryPackage.f90.
|
inherited |
Definition at line 62 of file prt-prp.f90.
|
inherited |
Definition at line 42 of file prt-prp.f90.
|
inherited |
Definition at line 76 of file BoundaryPackage.f90.
|
inherited |
Definition at line 41 of file NumericalPackage.f90.
|
inherited |
Definition at line 69 of file BoundaryPackage.f90.
|
inherited |
Definition at line 62 of file BoundaryPackage.f90.
|
inherited |
Definition at line 103 of file BoundaryPackage.f90.
|
inherited |
Definition at line 107 of file BoundaryPackage.f90.
|
inherited |
Definition at line 53 of file prt-prp.f90.
|
inherited |
Definition at line 108 of file BoundaryPackage.f90.
|
inherited |
Definition at line 54 of file prt-prp.f90.
|
inherited |
Definition at line 37 of file NumericalPackage.f90.
|
inherited |
Definition at line 47 of file prt-prp.f90.
|
inherited |
Definition at line 52 of file prt-prp.f90.
|
inherited |
Definition at line 83 of file BoundaryPackage.f90.
|
inherited |
Definition at line 68 of file BoundaryPackage.f90.
|
inherited |
Definition at line 94 of file BoundaryPackage.f90.
|
inherited |
Definition at line 40 of file NumericalPackage.f90.
|
inherited |
Definition at line 98 of file BoundaryPackage.f90.
|
inherited |
Definition at line 32 of file NumericalPackage.f90.
|
inherited |
Definition at line 31 of file NumericalPackage.f90.
|
inherited |
Definition at line 111 of file BoundaryPackage.f90.
|
inherited |
Definition at line 38 of file NumericalPackage.f90.
|
inherited |
Definition at line 71 of file BoundaryPackage.f90.
|
inherited |
Definition at line 45 of file NumericalPackage.f90.
|
inherited |
Definition at line 39 of file NumericalPackage.f90.
|
inherited |
Definition at line 44 of file NumericalPackage.f90.
|
inherited |
Definition at line 35 of file BoundaryPackageExt.f90.
|
inherited |
Definition at line 43 of file NumericalPackage.f90.
|
inherited |
Definition at line 42 of file NumericalPackage.f90.
|
inherited |
Definition at line 51 of file prt-prp.f90.
|
inherited |
Definition at line 61 of file BoundaryPackage.f90.
|
inherited |
Definition at line 66 of file BoundaryPackage.f90.
|
inherited |
Definition at line 45 of file prt-prp.f90.
|
inherited |
Definition at line 46 of file prt-prp.f90.
|
inherited |
Definition at line 50 of file prt-prp.f90.
|
inherited |
Definition at line 49 of file prt-prp.f90.
|
inherited |
Definition at line 48 of file prt-prp.f90.
|
inherited |
Definition at line 87 of file BoundaryPackage.f90.
|
inherited |
Definition at line 46 of file NumericalPackage.f90.
|
inherited |
Definition at line 49 of file BoundaryPackage.f90.
|
inherited |
Definition at line 44 of file prt-prp.f90.
|
inherited |
Definition at line 63 of file BoundaryPackage.f90.
|
inherited |
Definition at line 28 of file NumericalPackage.f90.
|
inherited |
Definition at line 29 of file NumericalPackage.f90.
|
inherited |
Definition at line 26 of file NumericalPackage.f90.
|
inherited |
Definition at line 67 of file BoundaryPackage.f90.
|
inherited |
Definition at line 64 of file BoundaryPackage.f90.
|
inherited |
Definition at line 65 of file BoundaryPackage.f90.
|
inherited |
Definition at line 102 of file BoundaryPackage.f90.
|
inherited |
Definition at line 73 of file BoundaryPackage.f90.
|
inherited |
Definition at line 41 of file BoundaryPackageExt.f90.
|
inherited |
Definition at line 74 of file BoundaryPackage.f90.
|
inherited |
Definition at line 70 of file BoundaryPackage.f90.
|
inherited |
Definition at line 68 of file prt-prp.f90.
|
inherited |
Definition at line 66 of file prt-prp.f90.
|
inherited |
Definition at line 67 of file prt-prp.f90.
|
inherited |
Definition at line 99 of file BoundaryPackage.f90.
|
inherited |
Definition at line 58 of file prt-prp.f90.
|
inherited |
Definition at line 112 of file BoundaryPackage.f90.
|
inherited |
Definition at line 34 of file NumericalPackage.f90.
|
inherited |
Definition at line 27 of file NumericalPackage.f90.
|
inherited |
Definition at line 84 of file BoundaryPackage.f90.
|
inherited |
Definition at line 49 of file NumericalPackage.f90.
|
inherited |
Definition at line 63 of file prt-prp.f90.
|
inherited |
Definition at line 64 of file prt-prp.f90.
|
inherited |
Definition at line 76 of file prt-prp.f90.
|
inherited |
Definition at line 43 of file BoundaryPackageExt.f90.
|
inherited |
Definition at line 36 of file BoundaryPackageExt.f90.
|
inherited |
Definition at line 37 of file BoundaryPackageExt.f90.
|
inherited |
Definition at line 77 of file BoundaryPackage.f90.
|
inherited |
Definition at line 74 of file prt-prp.f90.
|
inherited |
Definition at line 75 of file prt-prp.f90.
|
inherited |
Definition at line 69 of file prt-prp.f90.
|
inherited |
Definition at line 71 of file prt-prp.f90.
|
inherited |
Definition at line 72 of file prt-prp.f90.
|
inherited |
Definition at line 73 of file prt-prp.f90.
|
inherited |
Definition at line 70 of file prt-prp.f90.
|
inherited |
Definition at line 57 of file prt-prp.f90.
|
inherited |
Definition at line 56 of file prt-prp.f90.
|
inherited |
Definition at line 65 of file prt-prp.f90.
|
inherited |
Definition at line 80 of file BoundaryPackage.f90.
|
inherited |
Definition at line 79 of file BoundaryPackage.f90.
|
inherited |
Definition at line 59 of file prt-prp.f90.
|
inherited |
Definition at line 60 of file prt-prp.f90.
|
inherited |
Definition at line 93 of file BoundaryPackage.f90.
|
inherited |
Definition at line 50 of file BoundaryPackage.f90.
|
inherited |
Definition at line 38 of file BoundaryPackageExt.f90.
|
inherited |
Definition at line 92 of file BoundaryPackage.f90.
|
inherited |
Definition at line 89 of file BoundaryPackage.f90.
|
inherited |
Definition at line 104 of file BoundaryPackage.f90.
|
inherited |
Definition at line 105 of file BoundaryPackage.f90.
